Three Way Titanium Ball Valve Gr1 Gr2
Design Standard:API 6D, ASME B16.34
Operation Method:Lever, Gear, Actuator
Fire Safe:API 607, ISO 10497
Model:Ball Valve
Material:Titanium Alloy Gr1 Gr2
Operation:Manual, Pneumatic, Electric
Face To Face Dimension:ASME B16.10
Anti-Static:API 608
Three Way Titanium Ball Valve Gr1 Gr2
Product Description:
A three-way titanium ball valve is a specialized type of ball valve designed with three ports, allowing it to direct the flow of fluids in multiple directions. The construction of this valve takes advantage of titanium's superior properties, making it ideal for applications that require high corrosion resistance, strength, and durability. Below is a detailed overview of three-way titanium ball valves.
Three-way titanium ball valves can be classified into L-type (Q44F) and T-type (Q45F). Each type serves different functions in controlling the flow direction of the medium.
L-Type (Q44F) Three-Way Ball Valve:
The L-type three-way ball valve is primarily used for switching the flow direction of the medium. It allows the connection of two perpendicular channels, effectively changing the medium's path from one direction to another.
T-Type (Q45F) Three-Way Ball Valve:
The T-type three-way ball valve is designed for media distribution, confluence, and flow direction switching. It enables three channels to be interconnected, or alternatively, it can connect any two of the three channels. This versatile functionality allows for more complex flow control within a system.
Design & Testing International Standard of 3 Way Ball Valve:
| Design & Testing International Standard of 3 Way Ball Valve | |
| Design Standard | BS EN ISO 17292 (BS 5351) / BS EN ISO 12516 / BS EN 1983 / ASME B16.34 / API 6D |
| Inspection & TestingStandard | BS EN ISO 12266-(BS 6755 -1) |
| Flange To Flange Distance | Mfg. Standard |
| End Connection | Flanged End to ANSI B 16.5, Class 150 / 300 |
| BS 10 Table D E F / H | |
| PN 6 / PN 10 / PN 16 PN 25 PN 40 | |
| DIN Standard / JIS Standard / IS Standard | |
| Screwed / Threaded End to ANSI B 1.20.1 | |
| Manufacturing Size Range | 1/2"(DN15) to 12(DN 300) - Flanged Ends |
| 1/2"(DN15) to 3(DN 80) - Screwed Ends | |
| Pressure Rating of Valve | PN 10 / PN 16 / PN 25 / PN 40 |
| Valve Operation | Manual Hand Lever / Worm-Gear Actuator OperatedPneumatic Rotary Quarter Turn Actuator / Electrical Actuator |
